Description
The VHW-105 is a wall-mounted, 2-phase water purification plant that is designed to filter calcium and magnesium ions from the water, making your water less hard and removing limescale from the water. The mounted all-in-one filter cartridge also intercepts harmful chemicals, fine particles and chlorine. The final PP filtration filters out remaining impurities.
This all-in-one filter is suitable for municipal tap water. The UV lamp kills 99.9% of all bacteria and viruses. With this water purification system you have an affordable solution to protect your household appliances against hard water and you are guaranteed clean, pure and refreshing water that also tastes better!
Specifications
- Flow rate: 30 liters per minute.
- Housing material: stainless steel (ss304).
- Input voltage: 110-240 V, 50/60 Hz.
- Power output of UV lamp: 10,000 hours.
- Audible and visible alarm system.
- Inlet/outlet thread: 1 inch.
- Dimensions: 43.5 x 40 x 20 cm.
- UV dose: 30 mj/cm2.
- Size of Big Blue housing: 10 inch / 25 cm.
- Pre-filtration housing material: PVC.
Downloads
Click here for
Click here for
Installation manual Van Hall Innovations water purification systems
Click here for
Click here for
Information rainwater purification
Logistics
Box dimension
44 x 22 x 46 cm
Weight
9,70 kg
