The PH3-S103 uses 10 inch (25cm) Slim Blue water filters to effectively remove impurities and provides a flow rate of 4 liters per minute. In addition, this system uses UV LED water disinfection technology, which eliminates harmful microorganisms and purity of your drinking water is guaranteed.
We recommend replacing the filters every 3-6 months (depending on water quality).
Description
The PH3-S103 is an undersink, 5-phase wall mounted water purification system that is designed to provide clean and safe drinking water wherever you are.
The PH3-S103 uses 10 inch (25cm) Slim Blue water filters to effectively remove impurities and provides a flow rate of 4 liters per minute. In addition, this system uses UV LED water disinfection technology, which eliminates harmful microorganisms and purity of your drinking water is guaranteed.
With the slim and compact design of the PH3-S103, this water purification installation fits perfectly in any room. Due to its size, this water filter is ideal for holiday homes, campers, caravans, houseboats or simply under the kitchen sink at home.
1ST STAGE FILTRATION
PP filter
The PP filter is essential for reducing turbidity in the water by removing coarse particles. It also extends the life of other filters by preventing them from becoming clogged with sediment.
2ND STAGE FILTRATION
GAC filter
The GAC filter, which stands for Granular Activated Carbon filter, uses a bed of activated carbon to adsorb chlorine, chemicals, organics and unpleasant tastes and odors from the water. The filter media absorbs these contaminants, making the water purified, safe and refreshing.
3RD STAGE FILTRATION
CTO filter
The CTO filter, also known as a Chlorine, Taste, and Odor filter or carbon filter, uses activated carbon blocks to remove chlorine, unpleasant tastes and odors from the water. The filter medium adsorbs the contaminants, purifying the water.
4TH STAGE FILTRATION
T33 Post-activated carbon filter
The last filter your water passes through. T33 softens the water and removes limescale/scale. Additionally, it contains coconut grade activated grain carbon to remove any taste or odor issues.
5TH STAGE FILTRATION
UV filter
The UV filter kills up to 99.99% of coliform bacteria and various living contaminants to ensure safer drinking water for your family.
Specifications
Flow rate: 4LPM
Housing material: SS304
Input voltage: UV LED lamp works on 24, 110-230 volts
Adapter: 230V to 24V
Inlet/outlet port size: 1/2 inch or 3/4 inch female
Dimensions: 36 x 36 x 13.5 cm
Visual power indicator: Yes
Flow switch: Yes
Pre-filtration cartridge: PP + GAC + CTO + T33
Lifespan of filter use: 3 years for a family of 3-4 people
Latest UV LED technology
Integrated pre-filtration
No annual replacement of UV lamp or quartz tube required
